Aerospace Tools by HS Tooling
HS Tooling (previously Hi-Shear Tooling) aerospace riveting products are distributed in the United Kingdom by Wm. Lees & Sons Ltd.
The extensive range of HS Tooling’s specialist riveting tools can be supplied by us wherever you are, and we can also advise you on which tools best suit your riveting requirements.
Scroll down this page for a glimpse of the variety of tools available, from rivet hammers to rivet squeezers, and download any product spec sheet you are interested in.
You can be confident in HS Tooling’s excellent reputation for Aerospace Tools:
- High quality tools for aerospace and other demanding industrial environments
- Tools featuring superior performance coupled with excellent reliability
- Advanced ergonomic design for air tool operator comfort and safety
- Download the HS Tooling Riveter information
Download the HS Tooling Brochure for full product details
Get in touch today!
For orders and enquiries, contact us by telephone or email.
Callers within the UK, Tel: 01698 426662
Outwith the UK, Tel: +44 1698 426662
HS Tooling Aerospace Riveting Tools available from Wm. Lees & Sons Ltd. |
|||||||
|---|---|---|---|---|---|---|---|
| Rivet Hammers, Recoilless Rivet Hammers, Rivet Shavers and Bucking Bars… High quality aerospace tooling to tackle the most demanding riveting tasks. |
|||||||
 |
|||||||
HS Tooling Aerospace Drills |
Models | Power HP | Speed rpm | Chuck mm | Download | ||
| Drill CXD |  |
Easily manoeuvred into spaces too small for other drills. | 8 | 0.5 | 250 to 25,000 |
6.3 and 9.5 |
 |
| Drill CXT II |  |
With 1.5 HP, it has the power to drill through thick or hard materials, often in a single pass. | 8 | 1.5 | 750 to 20,000 |
6.3 9.5 12.5 |
|
HS Tooling Ultralite Compression Riveters – C-Yoke |
Capacity Alu mm | Capacity Steel mm | Length mm | Weight kg | Download | ||
|---|---|---|---|---|---|---|---|
| 705HF C |  |
Adjustable ultra light C yoke compression rivet squeezer with capacity up to 5/32″ aluminium and 1/8″ steel. | 4.0 | 3.2 | 260 | 2.0 | |
| 720HF C |  |
Adjustable ultra light C yoke compression rivet squeezer with capacity up to 1/4″ aluminium and 3/16″ steel. | 6.4 | 4.8 | 362 | 2.5 | |
| 735C |  |
Adjustable ultra light C yoke compression rivet squeezer with capacity up to 5/16″ aluminium and 1/4″ steel. | 7.9 | 6.4 | 525 | 4.6 | |
| 740C |  |
Adjustable ultra light C yoke compression rivet squeezer with capacity up to 3/16″ aluminium and 5/32″ steel. | 4.8 | 4.0 | 451 | 5.7 | |
| 745C |  |
Adjustable ultra light C yoke compression rivet squeezer with capacity up to 5/16″ aluminium and 1/4″ steel. | 7.9 | 6.4 | 444 | 4.5 | |
HS Tooling Ultralite Compression Riveters – Alligator |
Capacity Alu mm | Capacity Steel mm | Length mm | Weight kg | Download | ||
| 702A |  |
Ultra light alligator compression rivet squeezer with capacity up to 1/8″ aluminium and 3/32″ steel. Set holders in 3/16″ diameter available. |  |
||||
| 702TA |  |
Ultra light alligator compression rivet squeezer with capacity up to 5/32″ aluminium and 1/8″ steel. Set holders in 3/16 available. | |||||
| 710A HF |  |
Adjustable ultra light alligator compression rivet squeezer with capacity up to 3/16″ aluminium and 5/32″ steel. | 3.2 to 4.8 |
2.4 to 4.0 |
233 to 276 |
1.7 to 2.1 |
|
| 725A HF |  |
Adjustable ultralight alligator compression rivet squeezer with capacity up to 1/4″ aluminium and 3/16″ steel. | 4.0 to 6.4 |
3.2 to 4.8 |
305 to 350 |
2.5 to 2.8 |
|
| 735A HF |  |
Adjustable ultralight alligator compression rivet squeezer with capacity up to 1/4″ aluminium and 3/16″ steel. Set holders in 3/16″ and 5/32″ diameter available. | 4.0 to 6.4 |
3.1 to 4.8 |
513 to 622 |
4.0 to 6.0 |
|
| 740A |  |
Adjustable ultra light alligator compression rivet squeezer with capacity up to 5/16″ aluminium and 1/4″ steel. | 3.2 to 7.9 |
2.4 to 6.4 |
501 to 768 |
7.5 to 14.3 |
|
| 745A |  |
Adjustable ultra light alligator compression rivet squeezer with capacity up to 3/16″ aluminium and 5/32″ steel. | 4.0 to 4.8 |
3.2 to 4.0 |
444 to 571 |
5.9 to 7.2 |
|
| 750A |  |
Adjustable ultra light alligator compression rivet squeezer with capacity up to 5/16″ aluminium and 1/4″ steel. Set holders in 3/16″ and 1/4″ diameter available. | 4.8 to 7.9 |
4.0 to 6.4 |
635 to 790 |
8.6 to 13.1 |
|
